4U High Performance Industrial Server Chassis (14 slot)
Model：U4104N1000
• Dimension : 481mm x 450mm (D)x 4U
• M/B : Backplane Type(14Slot)
• Drive Bays : 5.25” x 3 , Exposed 3.5” x 1, Internal 3.5”x 1
• PSU Type : PSII Type PSU ,Mini Redundant PSU
Welcome any customized modification
Add to inquiry
• M/B : Backplane Type(14Slot)
• Drive Bays : 5.25” x 3 , Exposed 3.5” x 1, Internal 3.5”x 1
• PSU Type : PSII Type PSU ,Mini Redundant PSU
Welcome any customized modification
Features
► Unique Outlook Design
► Reliable Safety Device
► Super System Expansibility
► Easy Assembly & Service
► Effective cooling design to tackle thermal issues
► Model NO : U4004N1
U-Rack's 4U server chassis is a testament to innovative design and functionality. With its unique aesthetic, it houses a 14-slot backplane motherboard and provides versatile storage options with three 5.25" bays, one exposed 3.5" bay, and one internal 3.5" bay. Choose between a PSII type PSU or a mini redundant PSU for reliable power. The chassis boasts effective cooling to tackle thermal challenges, ensuring optimal performance. Super system expandability and easy assembly/service features make it adaptable to various configurations. U-Rack welcomes customized modifications, allowing you to tailor this chassis to your exact requirements, making it the ideal foundation for your high-performance server infrastructure.
Specification
| Model NO. | U4104N1000 |
| Standard | EIA-RS310D |
| Dimension (W x D x H) |
481mm x 450mm x 4U (18.9” x 17.7” x 7”) |
| Material | SGCC / 1.2mm thickness (Top cover 1.4mm) |
| M/B | Backplane Type(14 slot) |
| Drive bays | 5.25” x 3 , Exposed 3.5” x 1, Internal 3.5”x 1 |
| Coolings | 1 x 12cm ball bearing (middle) |
| Indicators | Power, HDD, Fan fail LED |
| Controls | Power on/off, system reset, alarm Reset, USB port x 1 |
| Power Supply | PS2 Type PSU (300W ~ 500W) 300 / 400W Mini Redundant PSU |
