1U short depth 4-bay Compact Server Chassis
Model：U1200N4000
• Dimension : 481mm x 494mm x 1U
• M/B : MICRO ATX (9.6” X 9.6”)
• Drive Bays : 3.5” HDD x4
• PSU Type : 1U Flex PSU
Welcome any customized modification
Add to inquiry
• M/B : MICRO ATX (9.6” X 9.6”)
• Drive Bays : 3.5” HDD x4
• PSU Type : 1U Flex PSU
Welcome any customized modification
Features
With dimensions measuring 481mm x 494mm x 1U, this 1U case strikes a balance between space-saving design and performance. It is specifically designed to support a MICRO ATX (9.6" x 9.6") motherboard, providing a solid foundation for a compact and efficient computing system.
1U case features four 3.5" HDD drive bays, offering ample space for storing and managing your essential data. This ensures efficient data storage and quick access to your files whenever needed.
Powering this versatile chassis is a 1U Flex PSU (Power Supply Unit). This specialized power supply ensures a stable and reliable power source, minimizing the risk of disruptions or failures that could impact system performance or compromise data integrity.
Specification
| Model NO. | U1200N4000 |
| Standard | EIA-RS310D |
| Dimension | 481mm x 494mm x 1U |
| (W x D x H) | (18.9” x 19.5” x 1.7”) |
| Material | SGCC / 1.0mm thickness, Aluminum front plate |
| M/B | MICRO ATX (9.6” X 9.6”) |
| Drive bays | 3.5” HDD x4 |
| Coolings | 3x 4cm |
| Indicators | Power, HDD LED |
| Controls | Power on/off, USB2.0/3.0(OPT) port x 2 |
| Slots | 1 (PCI or PCI-E) |
| Power Supply | 1U Flex PSU |
